Sapphire Louvres Ltd

Sapphire Louvres Ltd are specialists in the manufacture and supply of made to measure louvres grills and window ventilation to the architectural industry. We have a full powder coating facility on site which allows us to offer a quick turnaround.

Service
Service is very important to us and our friendly team of staff will ensure our customers are cared for from enquiry right through to after care service.

Products
We work very hard to ensure our products are of the highest quality whilst streamlining our manufacturing process passing on the savings to our customers.

Our range of products includes the following Duco System Styles, click product to see details:

F30Z Heavy Duty Glazed in Louvre
The F30Z Louvre is designed to be glazed in to window or door profiles to replace double glazed units. The Z type blade ensures a robust design. The perforated blade acts as an insect screen.

Specification:

• Glazing widths of 24mm, 28mm or 32mm
• 3 types of integrated mesh, Insect, Bird or Non Punched
• Can Achieve up to 48% air flow
• Available in any Standard RAL or BS polyester Powder coated finish. Also available in an anodised finish

Extras

• Backing Panels
• Aluminium or Steel
• Insulated
• Sandwich Panel

G30Z Wall Mounted Louvre
The G30Z is a surface mounted wall unit that can be used for many hole in the wall applications, the perforated blade as an insect screen.

Spec:

• Glazing widths 24mm, 28mm or 32mm as standard
• 3 types of integrated mesh, Insect, Bird or non punched
• Can achieve up to 48% air flow
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish

Extras:

• Backing Panels
• Aluminium or Steel
• Insulated
• Sandwich Panel

M30Z Wall Mounted Security
The M30Z is a surface mounted wall unit for ‘hole in the wall’ applications.

50 HP High Performance Louvre
The 50 HP Louvre offers high performance, giving high air flow but low water penetration. it has been developed especially for intensive ventilation, this system allows large quantities of air flow to be introduced or removed from a space using minimal surface.

Can be supplied with a selection of different types of outer frame options. Insect/Bird mesh as an option.

Specification:

• Can be manufactured to almost any width/height
• Physical free Area 68%
• Can Achieve up to 48% air flow
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish

Extras:

• Backing Panels
• Insulated
• Sandwich Panel

50/75Z Louvre
The 50/75Z Louvre can be a recessed wall mounted louvre system or with Glazing legs to suit, insect mesh fitted as an option.

Spec:

• We can manufacture to any width/height
• Physical Free Area 47%
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish
• Available in 50mm or 75mm pitch

Duco Plus 45 Vent
Duco Plus 45 is a controllable glazed in window ventilator, which directs the flow of incoming air upwards.

Spec:

• Available in 24mm, 28mm or 32mm glazing
• Black or white End caps
• Glass reduction of 45mm
• Ventilator height 60mm
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish

Duco Plus 60 Vent
The Duco Plus 60 is a thermally broken and glazed in window vent, which directs the flow of incoming air upwards.

Spec:

• Available in 24mm, 28mm or 32mm glazing
• Black or white End caps
• Glass reduction of 60mm
• Ventilator height 75mm
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish

Duco Flat 80 Vent
The Duco Flat 80 provides a completely flat appearance, these are suitable for use on the fixed pane of a sliding window. It comes with a thumb control handle.

Specification:

• Glass reduction 80mm
• Ventilator height 95mm
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish

Duco Strip Slot Vents
The Duco Strip is an aluminium through the frame ventilator, these are suitable for any type of window frame.

Specification:

• Available in slim line as standard and wide line on request
• Option of black or white end caps
• Any width up to 500mm
• Available in any standard RAL or BS polyester Powder coated finish. Also available in an anodised finish
